| Brand | New Holland Tractors |
|---|---|
| Cylinder | 3 |
| HP Category | 39HP |
| Gear Box | 8 Forward + 2 Reverse |
| Brakes | Mechanical, Real Oil Immersed Brakes |
| Warranty | 6000 Hours or 6 Year |
New Holland 3037 TX
MAIN FEATURES
- Max useful power - 35hp PTO Power & 30.2hp Drawbar Power
- Max Torque - 149.6 Nm
- Eptraa PTO
- Independent PTO Clutch Lever*
- SOFTEK CLUTCH
- Fully Constant Mesh AFD
- HP Hydraulic with Lift-O-Matic & 1800 KG Lift Capacity
- Multisensing with DRC Valve
- Straight Axle Planetary Drive
New Holland 3037 TX FULL SPECIFICATION
New Holland 3037 TX Engine
No. Of Cylinder
3
HP Category
39 HP
Capacity CC
2500 CC
Engine Rated RPM
2000 RPM
Air Filter
Oil Bath With Pre Cleaner
PTO HP
35 HP
New Holland 3037 TX Transmission(GearBox)
Clutch Type
Double/Single*
Transmission Type
Fully Constantmesh AFD
Gear Box
8 Forward + 2 Reverse, 8 Froward + 8 Reverse Synchro Shuttle
Battery
75 Ah
Alternator
35 Amp
Forward Speed
2.54- 28.16 kmph
Reverse Speed
3.11- 19.22 kmph
New Holland 3037 TX Brakes
Brake Type
Mechanical, Real Oil Immersed Brakes
New Holland 3037 TX Steering
Steering Type
Mechanical/Power Steering (optional)
New Holland 3037 TX Power Take Off
PTO Type
6 Splines
PTO rpm
540
New Holland 3037 TX Fuel Capacity
Fuel Tank Capacity
42 Liter
New Holland 3037 TX Dimension and Weight
Weight
1800 KG
Wheelbase
1865 MM
Overall Length
3590 MM
Tractor Width
1680 MM
Ground Clearance
364 MM
New Holland 3037 TX Lifting Capacity(Hydraulics)
Lifting Capacity in Kg
1800 Kgf
3 point Linkage
Automatic Depth and Draft Control, Lift- O-Matic, Response Control, Multiple Sensitivity Control, I
New Holland 3037 TX Tyre Size
Front
6.00 x 16 / 6.50 x 16
Rear
13.6 x 28
New Holland 3037 TX Additional Features
Accessories
Tools, Bumpher, Top Link, Canopy, Hitch, Drawbar, Ballast Weight
Status
Launched
