| Brand | Swaraj |
|---|---|
| Cylinder | 2 |
| HP Category | 30HP |
| Gear Box | 6 Forward + 2 Reverse |
| Brakes | Oil Immersed Brakes |
| Warranty | N/A |
Swaraj 724 XM ORCHARD NT
724 XM Orchard NT is a 18.64-22.37 kW (25-30hp) category tractor. It is fitted with powerful & fuel efficient two-cylinder water-cooled engine. Its outer to outer width has been narrowed to 1092 mm which makes it highly suitable for inter-cultivation & orchard operations. The 724 XM Orchard NT comes equipped with host of features like power steering with separate steering oil tank, oil immersed brakes that provide operator comfort & safety etc. It is suitable for PTO driven implements like sprayer, rotavator etc. as it comes with a 540 PTO r/min. The adjustable check chains provided in it help in preventing crop damage.
Swaraj 724 XM ORCHARD NT FULL SPECIFICATION
Swaraj 724 XM ORCHARD NT Engine
No. Of Cylinder
2
HP Category
30 HP
Capacity CC
1824 CC
Engine Rated RPM
1800 RPM
Air Filter
Dry type with dual element
PTO HP
21.1 HP
Cooling System
Water Cooled with No loss tank
Swaraj 724 XM ORCHARD NT Transmission(GearBox)
Clutch Type
Single Friction Plate
Transmission Type
Constant mesh
Gear Box
6 Forward + 2 Reverse
Battery
12 V 75 Ah
Alternator
Starter Motor & Alternator
Forward Speed
2.2 - 23.3 kmph
Reverse Speed
2.2 - 8.7 kmph
Swaraj 724 XM ORCHARD NT Brakes
Brake Type
Oil Immersed Brakes
Swaraj 724 XM ORCHARD NT Steering
Steering Type
Power Steering
Swaraj 724 XM ORCHARD NT Power Take Off
PTO Type
6 Splines
PTO rpm
540
PTO Power
21.1
Swaraj 724 XM ORCHARD NT Fuel Capacity
Fuel Tank Capacity
35 litre
Swaraj 724 XM ORCHARD NT Dimension and Weight
Weight
1495 KG
Wheelbase
1550 MM
Overall Length
2900 MM
Tractor Width
1092 MM
Ground Clearance
220 MM
Swaraj 724 XM ORCHARD NT Lifting Capacity(Hydraulics)
Lifting Capacity in Kg
1000 Kg
3 Point Linkage(Mm)
CAT- 1 & 2
Swaraj 724 XM ORCHARD NT Tyre Size
Front
5.00 X 15
Rear
9.50 X 24
Swaraj 724 XM ORCHARD NT Additional Features
Accessories
2000 Hours or 2 Year
Status
Launched
