FIELDKING-Compact Model Disc Harrow (Auto Angle Adjustment) FKCMDHAAA -24-18
| Brand | FIELDKING |
|---|---|
| Model Name | FKCMDHAAA-24-18 |
| Implement Type | TILLAGE |
| Category | HARROW |
| Implement Power | 60-70 |
FIELDKING-Compact Model Disc Harrow (Auto Angle Adjustment) FKCMDHAAA -24-18
MAIN FEATURES
- Used in open field working for the superficial ploughing, for the shattering of clods, preparation of soil for sowing, burial of organic substances & remains.
- It can be used in both forms i.e. mounted as well as trailed.
- High quality boron steel disc with 48~52 HRC hardness.
- Tillage depth of the harrow is 152~203 mm.
- Easily transportable - as it gets easily attached and mounted.
- Adjustable gang axles angle up to 46°
FIELDKING-Compact Model Disc Harrow (Auto Angle Adjustment) FKCMDHAAA -24-18 FULL SPECIFICATION
| FIELDKING-Compact Model Disc Harrow (Auto Angle Adjustment) FKCMDHAAA -24-18 Implements | |
|---|---|
| Working Width(Mm/Inch) | 212.8 |
| Gang Bolt/Axle (Mm/Inch) | 32/1.3"(Solid Sq. Rod) |
| No. of Discs | 18 |
| Type Of Disc | Notched Disc in Front Gang & Plain Disc in Rear Gang |
| Disc Diameter (Mm) | 610/24" x 4.5(T), 660/26" x 5(T) |
| Distance Between Disc (Mm/Inch) | 228/9" |
| Bearing Hubs | 8 |
| Weight(Kg/Lbs) | 960/2116 |
