FIELDKING-Mounted Offset Disc Harrow FKMODH -22-24
| Brand | FIELDKING |
|---|---|
| Model Name | FKMODH 22-24 |
| Implement Type | TILLAGE |
| Category | HARROW |
| Implement Power | 90-100 |
FIELDKING-Mounted Offset Disc Harrow FKMODH -22-24
MAIN FEATURES
- Used in open field working for the superficial ploughing, for the shattering of clods, preparation of soil for sowing, burial of organic substances & remains.
- It can be used in light and medium soil.
- High quality boron steel disc with 48~52 HRC hardness.
- Tillage depth of the harrow is 127~178 mm.
- Easily transportable - as it gets easily attached and mounted.
FIELDKING-Mounted Offset Disc Harrow FKMODH -22-24 FULL SPECIFICATION
| FIELDKING-Mounted Offset Disc Harrow FKMODH -22-24 Implements | |
|---|---|
| Gang Bolt/Axle (Mm/Inch) | 28/1.1''(SOLID SQ ROD) |
| Type Of Disc | NOTCHED DISC IN FRONT GANG & PLAIN DISC IN REAR GANG |
| Disc Diameter (Mm) | 508 X 3 T (20) OR 560 X 4 T (22) |
| Distance Between Disc (Mm/Inch) | 228/9 |
| Bearing Hubs | 8 |
| Weight(Kg/Lbs) | 731/1612 |
