ACE Tractors ACE DI-305 NG

Rating: 5.00
Brand ACE Tractors
Cylinder 2
HP Category 40HP
Gear Box 8 Forward + 2 Reverse
Brakes Oil Immersed/Dry Disc Brakes
Warranty 2000 Hours or 2 Year

ACE Tractors ACE DI-305 NG

A brief explanation about ACE DI-305 NG in India


ACE DI-305 NG tractor can perform multiple agricultural operations like sowing, tilling and harvesting. This ACE DI NG series tractor is a 26 Horsepower model that has two- cylinder units and has a 2044 CC displacement capacity. The best part is this tractor offers 1800 engine rated Revolution Per Minute.


Special features:


The ACE DI-305 NG is manufactured with a dry-type based single clutch for effective control on the roads.

This tractor model has 27.78 Km/hr maximum and 2.29 kmph minimum forward speed.

The tractor is designed fitted with 8 forward gears plus 2 reverse gears.

The tractor has disc/oil-immersed brakes options for more safety.

In addition, It has a smooth single based drop arm steering type for hassle-free riding experience.

Moreover, it has a 55L fuel tank which provides long performance and It is configured with modern hydraulic load-lifting power and has a lift/pulling 1200 kg.

The tractor has a gear ratio with 8 forward plus 2 reverse combinations of gears.

Why consider buying an ACE DI-305 NG  in India?


ACE is a renowned brand for tractors and other types of farm equipment. ACE has many extraordinary tractor models, but the ACE DI-305 NG is among the popular offerings by the ACE company. This tractor reflects the high power that customers expect. ACE is committed to providing reliable and efficient engines and tractors built to help customers grow their businesses.



At Tractorchoice you get all the data related to all types of tractors, implements and any other farm equipment and tools. Tractorchoice also offers information as well as assistance on tractor prices, tractor-related blogs, photos, videos and updates.




ACE DI-305 NG FULL SPECIFICATION

ACE Tractors ACE DI-305 NG Engine

No. Of Cylinder

2

HP Category

40 HP

Capacity CC

2858 CC

Engine Rated RPM

1800 RPM

Air Filter

Dry Air Cleaner

PTO HP

36.7 HP

Cooling System

Water Cooled

ACE Tractors ACE DI-305 NG Transmission(GearBox)

Clutch Type

Double Clutch

Gear Box

8 Forward + 2 Reverse

Battery

12 V 88 AH

Alternator

12 V 42 A

Forward Speed

2.37-28.71 kmph

Reverse Speed

2.96- 11.69 Km/h

Rear Axle

Direct Rear Axle

ACE Tractors ACE DI-305 NG Brakes

Brake Type

Dry Disc Brakes/ OIB OPTIONAL

ACE Tractors ACE DI-305 NG Steering

Steering Type

Mechanical /Single Drop Arm

ACE Tractors ACE DI-305 NG Power Take Off

PTO Type

6 Spline

PTO rpm

540

ACE Tractors ACE DI-305 NG Fuel Capacity

Fuel Tank Capacity

55 litre

ACE Tractors ACE DI-305 NG Dimension and Weight

Weight

1930 Kg (With Oil)

Wheelbase

1960 MM

Overall Length

3660 MM

Tractor Width

1740 MM

Ground Clearance

420 MM

ACE Tractors ACE DI-305 NG Lifting Capacity(Hydraulics)

Lifting Capacity in Kg

1200 Kg

ACE Tractors ACE DI-305 NG Tyre Size

Front

6.00 x 16

Rear

13.6 x 28

ACE Tractors ACE DI-305 NG Additional Features

Status

Launched
