| Brand | NEW HOLLAND |
|---|---|
| Cylinder | 3 |
| HP Category | 42HP |
| Gear Box | 8 Forward + 2 reverse |
| Brakes | Mechanical/Oil Immersed Brakes |
| Warranty | 6000 Hours or 6 Year |
New Holland 3230 NX
MAIN FEATURES
- Max useful power - 39 hp PTO Power & 31 hp Drawbar Power
- Max Road Speed (33.06 KMPH @ Rated RPM)
- Fully Constant Mesh AFD
- SOFTEK Clutch
- ECONOMY PTO with PTO Clutch
- HP Hydraulic with Lift-O-Matic & 1500 KG Lift Capacity
- Multisensing with DRC Valve
- Real Oil Immersed Brakes
New Holland 3230 NX FULL SPECIFICATION
New Holland 3230 NX Engine
No. Of Cylinder
3
HP Category
42 HP
Capacity CC
2500 CC
Engine Rated RPM
2000 RPM
Air Filter
Oil Bath with Pre-Cleaner
PTO HP
39 HP
New Holland 3230 NX Transmission(GearBox)
Clutch Type
Single / Dual (Optional)
Transmission Type
Fully Constant Mesh AFD
Gear Box
8 Forward + 2 Reverse
Battery
75 Ah
Alternator
35 Amp
Forward Speed
2.92 – 33.06 kmph
Reverse Speed
3.61 – 13.24 kmph
New Holland 3230 NX Brakes
Brake Type
Mechanical, Real Oil Immersed Brakes
New Holland 3230 NX Steering
Steering Type
Mechanical/Power Steering (optional)
New Holland 3230 NX Fuel Capacity
Fuel Tank Capacity
42 litre
New Holland 3230 NX Dimension and Weight
Weight
1750 KG
Wheelbase
1910 MM
Overall Length
3270 MM
Tractor Width
1682 MM
Ground Clearance
385 MM
New Holland 3230 NX Lifting Capacity(Hydraulics)
Lifting Capacity in Kg
1500 Kg
New Holland 3230 NX Tyre Size
Front
6.00 x 16
Rear
13.6 x 28
New Holland 3230 NX Additional Features
Status
Launched
