| Brand | New Holland |
|---|---|
| Cylinder | 3 |
| HP Category | 50HP |
| Gear Box | 8 Forward + 2 Reverse / 12 Forward + 3 Reverse Creeper, 12 Forward + 3 Reverse UG |
| Brakes | Real Oil Immersed Multi Disk Brake |
| Warranty | 6000 Hours / 6 Year |
New Holland 3630 TX Special Edition 4WD
New Holland 3630 TX Special Edition 4WD FULL SPECIFICATION
New Holland 3630 TX Special Edition 4WD Engine
No. Of Cylinder
3
HP Category
50 HP
Capacity CC
2931 CC
Engine Rated RPM
2100 RPM
Air Filter
Dry Type Air Cleaner
PTO HP
46 HP
New Holland 3630 TX Special Edition 4WD Transmission(GearBox)
Clutch Type
Double Clutch with Independent PTO Clutch Lever
Transmission Type
Constant Mesh/Partial Synchro Mesh
Gear Box
8 Forward + 2 Reverse / 12 Forward + 3 Reverse Creeper, 12 Forward + 3 Reverse UG
Battery
88 Ah
Alternator
45 Amp
Forward Speed
0.94 - 31.60 kmph
Reverse Speed
1.34 - 14.86 kmph
New Holland 3630 TX Special Edition 4WD Brakes
Brake Type
Real Oil Immersed Multi Disk Brake
New Holland 3630 TX Special Edition 4WD Steering
Steering Type
Power Steering
New Holland 3630 TX Special Edition 4WD Power Take Off
PTO Type
GSPTO / RPTO*
PTO rpm
540
New Holland 3630 TX Special Edition 4WD Fuel Capacity
Fuel Tank Capacity
60 litre
New Holland 3630 TX Special Edition 4WD Dimension and Weight
Weight
2495 KG
Wheelbase
1985 MM
Overall Length
3700 MM
Tractor Width
1960 MM
Ground Clearance
390 MM
New Holland 3630 TX Special Edition 4WD Lifting Capacity(Hydraulics)
Lifting Capacity in Kg
1700 / 2000 Kg
New Holland 3630 TX Special Edition 4WD Tyre Size
Front
9.50 X 24
Rear
16.9 x 28
New Holland 3630 TX Special Edition 4WD Additional Features
Accessories
Tools, Bumper, Ballast Weight, Top Link, Canopy
Status
Launched
